Greenwood Lake’s “Champagne Lady”

or ‘The New Jersey Connie’



Specifications and Advertising







NOTE: If you have solid information about, and/or more photos of this particular airplane from anytime between 1946 and 1990, please contact me to include them here! Click here to Email me!



Technical Information for the Model L-049 Model Constellations.



This section will attempt to provide the most complete listing of specifications for the Model L-049 Constellations I can gather. It may start out rather small, but I expect to expand it greatly as I gather more information. Rest assured, I plan to provide far more than just length, width and height and its top speed. I will also try to provide cross-reference information to other Constellation models where they relate directly to the L-049 in some significant way.



Lockheed Constellation, Model L-049-46

Lockheed’s first civilian Constellation Model

Construction # 2072

Air France’s first Constellation

Initial registration:

F-BAZA (Air France), 1946-1950

Subsequent registration:

N9412H, 1950-present





Wingspan:                                    123 feet



Wing Area                                      1650 square feet



Length                                            95 feet, 3 inches (97 feet, 5 inches with retrofitted weather radar nose)



Height                                             23 feet, 8 inches



Cabin Length                               64 feet, 9 inches



Cabin Width                                  10 feet, 8.6 inches



Cabin Height                                  6 feet, 6 inches



Empty Weight                               48,630 to 49,392 pounds



Engines Type                               R-3350-BA-3



Engines Power                            8,800 horsepower (2,200 hp per engine)



Maximum Takeoff Weight         86,250 pounds



Maximum Landing Weight        75,000 pounds



Maximum Payload                      18,423 pounds



Maximum Speed                          339 miles per hour (295 knots)



Cruise Speed                               313 miles per hour (272 knots)



Range w/ Maximum Fuel           3,995 miles (3,470 nautical miles)



Range w/ Maximum Payload    2,290 miles



Service Ceiling                             25,300 feet





Quantity Produced                     88 *



Construction numbers              1961 thru 1980 (20 units) and

                                                         2021 thru 2088 (68 units)



* Note: The first 14 planes and the 19^th plane ( C/n’s 1961-1974 and 1979), a total of 15 planes, were constructed as military model C-69 variations due to the US’ entry into World War Two, but most never saw any military usage as they were completed too late in the war. They were returned to Lockheed’s upgrades and alterations subsidiary to be converted to L-049 specs for commercial airline use while production of more new L-049s continued at the factory.



Advertising



This section showcases a few of the more interesting (to me) advertisements that feature the Constellation. I’m most interested in those that feature clear, descriptive and accurate artwork and photos. The words are not often the reason I include an ad.



( Click any image for a large-scale version of the complete ad. )



Lockheed Ad

Time Magazine, February 4, 1946



Lockheed Ad

Time Magazine, April 29, 1946



Air France Ad

Time Magazine, July 21, 1947



US 15-cent stamps



Republic of Guinea stamps

(note the Air France livery)
